What is Aluminum Seamless Pipe
The seamless aluminum pipe is made by the pure aluminum or aluminum alloy by extrusion processing along its longitudinal length of the hollow aluminum tube without weld. Because of no weld seams. It is preferred for pressure vessels. It is easy to see the uniform anodizing appearance of the seamless aluminum pipe. In the heavier wall section of the aluminum pipe. Some industrial projects use aluminum seamless to increase structural integrity. To let the structure be more safety.
What is Aluminum Seamless Pipe
The seamless aluminum pipe is made by the pure aluminum or aluminum alloy by extrusion processing along its longitudinal length of the hollow aluminum tube without weld. Because of no weld seams. It is preferred for pressure vessels. It is easy to see the uniform anodizing appearance of the seamless aluminum pipe. In the heavier wall section of the aluminum pipe. Some industrial projects use aluminum seamless to increase structural integrity. To let the structure be more safety.
Size of Aluminum Seamless Pipe
Pipe Size | Diameter Inches | Wall Thickness | |
Inches | OD | ID | |
1/8 | 0.405 | 0.269 | 0.068 |
0.405 | 0.215 | 0.095 | |
1/4 | 0.54 | 0.364 | 0.088 |
0.54 | 0.302 | 0.119 | |
3/8 | 0.675 | 0.493 | 0.091 |
0.675 | 0.423 | 0.126 | |
1/2 | 0.84 | 0.71 | 0.065 |
0.84 | 0.674 | 0.083 | |
0.84 | 0.622 | 0.109 | |
0.84 | 0.546 | 0.147 | |
0.84 | 0.464 | 0.188 | |
3/4 | 1.05 | 0.92 | 0.065 |
1.05 | 0.884 | 0.083 | |
1.05 | 0.824 | 0.113 | |
1.05 | 0.742 | 0.154 | |
1.05 | 0.612 | 0.219 | |
1 | 1.315 | 1.185 | 0.065 |
1.315 | 1.097 | 0.109 | |
1.315 | 1.049 | 0.133 | |
1.315 | 0.957 | 0.179 | |
1.315 | 0.815 | 0.25 | |
1-1/4 | 1.66 | 1.53 | 0.065 |
1.66 | 1.442 | 0.109 | |
1.66 | 1.38 | 0.14 | |
1.66 | 1.278 | 0.191 | |
1.66 | 1.16 | 0.25 | |
1-1/2 | 1.9 | 1.77 | 0.065 |
1.9 | 1.682 | 0.109 | |
1.9 | 1.61 | 0.145 | |
1.9 | 1.5 | 0.2 | |
1.9 | 1.338 | 0.281 | |
2 | 2.375 | 2.245 | 0.065 |
2.375 | 2.157 | 0.109 | |
2.375 | 2.067 | 0.154 | |
2.375 | 1.939 | 0.218 | |
2.375 | 1.687 | 0.344 | |
2-1/2 | 2.875 | 2.709 | 0.083 |
2.875 | 2.635 | 0.12 | |
2.875 | 2.469 | 0.203 | |
2.875 | 2.323 | 0.276 | |
2.875 | 2.125 | 0.375 | |
3 | 3.5 | 3.334 | 0.083 |
3.5 | 3.26 | 0.12 | |
3.5 | 3.068 | 0.216 | |
3.5 | 2.9 | 0.3 | |
3.5 | 2.624 | 0.438 | |
3-1/2 | 4 | 3.834 | 0.083 |
4 | 3.706 | 0.12 | |
4 | 3.548 | 0.226 | |
4 | 3.364 | 0.318 | |
4 | 4.5 | 4.334 | 0.083 |
4.5 | 4.26 | 0.12 | |
4.5 | 4.026 | 0.237 | |
4.5 | 3.826 | 0.337 | |
4.5 | 3.624 | 0.438 | |
4.5 | 3.438 | 0.531 | |
5 | 5.563 | 5.345 | 0.109 |
5.563 | 5.295 | 0.134 | |
5.563 | 5.047 | 0.258 | |
5.563 | 4.813 | 0.375 | |
5.563 | 4.563 | 0.5 | |
5.563 | 4.313 | 0.625 | |
6 | 6.625 | 6.407 | 0.109 |
6.625 | 6.357 | 0.134 | |
6.625 | 6.065 | 0.28 | |
6.625 | 5.761 | 0.432 | |
6.625 | 5.501 | 0.562 | |
6.625 | 5.189 | 0.719 | |
8 | 8.625 | 8.407 | 0.109 |
8.625 | 8.329 | 0.148 | |
8.625 | 8.125 | 0.25 | |
8.625 | 8.071 | 0.277 | |
8.625 | 7.981 | 0.322 | |
8.625 | 7.813 | 0.406 | |
8.625 | 7.625 | 0.5 | |
8.625 | 7.437 | 0.594 | |
8.625 | 7.187 | 0.719 | |
8.625 | 7.001 | 0.812 | |
8.625 | 6.813 | 0.906 | |
10 | 10.75 | 10.482 | 0.134 |
10.75 | 10.42 | 0.165 | |
10.75 | 10.25 | 0.25 | |
10.75 | 10.136 | 0.307 | |
10.75 | 10.02 | 0.365 | |
10.75 | 9.75 | 0.5 | |
10.75 | 9.562 | 0.594 | |
10.75 | 9.312 | 0.719 | |
12 | 12.75 | 12.438 | 0.156 |
12.75 | 12.39 | 0.18 | |
12.75 | 12.25 | 0.25 | |
12.75 | 12.09 | 0.33 | |
12.75 | 11.938 | 0.406 | |
12.75 | 11.626 | 0.562 | |
12.75 | 11.374 | 0.688 |
Size of Aluminum Seamless Pipe
Pipe Size | Diameter Inches | Wall Thickness | |
Inches | OD | ID | |
1/8 | 0.405 | 0.269 | 0.068 |
0.405 | 0.215 | 0.095 | |
1/4 | 0.54 | 0.364 | 0.088 |
0.54 | 0.302 | 0.119 | |
3/8 | 0.675 | 0.493 | 0.091 |
0.675 | 0.423 | 0.126 | |
1/2 | 0.84 | 0.71 | 0.065 |
0.84 | 0.674 | 0.083 | |
0.84 | 0.622 | 0.109 | |
0.84 | 0.546 | 0.147 | |
0.84 | 0.464 | 0.188 | |
3/4 | 1.05 | 0.92 | 0.065 |
1.05 | 0.884 | 0.083 | |
1.05 | 0.824 | 0.113 | |
1.05 | 0.742 | 0.154 | |
1.05 | 0.612 | 0.219 | |
1 | 1.315 | 1.185 | 0.065 |
1.315 | 1.097 | 0.109 | |
1.315 | 1.049 | 0.133 | |
1.315 | 0.957 | 0.179 | |
1.315 | 0.815 | 0.25 | |
1-1/4 | 1.66 | 1.53 | 0.065 |
1.66 | 1.442 | 0.109 | |
1.66 | 1.38 | 0.14 | |
1.66 | 1.278 | 0.191 | |
1.66 | 1.16 | 0.25 | |
1-1/2 | 1.9 | 1.77 | 0.065 |
1.9 | 1.682 | 0.109 | |
1.9 | 1.61 | 0.145 | |
1.9 | 1.5 | 0.2 | |
1.9 | 1.338 | 0.281 | |
2 | 2.375 | 2.245 | 0.065 |
2.375 | 2.157 | 0.109 | |
2.375 | 2.067 | 0.154 | |
2.375 | 1.939 | 0.218 | |
2.375 | 1.687 | 0.344 | |
2-1/2 | 2.875 | 2.709 | 0.083 |
2.875 | 2.635 | 0.12 | |
2.875 | 2.469 | 0.203 | |
2.875 | 2.323 | 0.276 | |
2.875 | 2.125 | 0.375 | |
3 | 3.5 | 3.334 | 0.083 |
3.5 | 3.26 | 0.12 | |
3.5 | 3.068 | 0.216 | |
3.5 | 2.9 | 0.3 | |
3.5 | 2.624 | 0.438 | |
3-1/2 | 4 | 3.834 | 0.083 |
4 | 3.706 | 0.12 | |
4 | 3.548 | 0.226 | |
4 | 3.364 | 0.318 | |
4 | 4.5 | 4.334 | 0.083 |
4.5 | 4.26 | 0.12 | |
4.5 | 4.026 | 0.237 | |
4.5 | 3.826 | 0.337 | |
4.5 | 3.624 | 0.438 | |
4.5 | 3.438 | 0.531 | |
5 | 5.563 | 5.345 | 0.109 |
5.563 | 5.295 | 0.134 | |
5.563 | 5.047 | 0.258 | |
5.563 | 4.813 | 0.375 | |
5.563 | 4.563 | 0.5 | |
5.563 | 4.313 | 0.625 | |
6 | 6.625 | 6.407 | 0.109 |
6.625 | 6.357 | 0.134 | |
6.625 | 6.065 | 0.28 | |
6.625 | 5.761 | 0.432 | |
6.625 | 5.501 | 0.562 | |
6.625 | 5.189 | 0.719 | |
8 | 8.625 | 8.407 | 0.109 |
8.625 | 8.329 | 0.148 | |
8.625 | 8.125 | 0.25 | |
8.625 | 8.071 | 0.277 | |
8.625 | 7.981 | 0.322 | |
8.625 | 7.813 | 0.406 | |
8.625 | 7.625 | 0.5 | |
8.625 | 7.437 | 0.594 | |
8.625 | 7.187 | 0.719 | |
8.625 | 7.001 | 0.812 | |
8.625 | 6.813 | 0.906 | |
10 | 10.75 | 10.482 | 0.134 |
10.75 | 10.42 | 0.165 | |
10.75 | 10.25 | 0.25 | |
10.75 | 10.136 | 0.307 | |
10.75 | 10.02 | 0.365 | |
10.75 | 9.75 | 0.5 | |
10.75 | 9.562 | 0.594 | |
10.75 | 9.312 | 0.719 | |
12 | 12.75 | 12.438 | 0.156 |
12.75 | 12.39 | 0.18 | |
12.75 | 12.25 | 0.25 | |
12.75 | 12.09 | 0.33 | |
12.75 | 11.938 | 0.406 | |
12.75 | 11.626 | 0.562 | |
12.75 | 11.374 | 0.688 |
Manufacturing Process of Aluminum Seamless Pipe
The seamless aluminum pipe is produced using two methods. First, Pushing a hollow aluminum billet through a die and mandrel press with tremendous force at high temperatures. And the other, Using a solid billet through a piercer press and then a mandrel pierces and extrudes the billet in a second forward stroke. Regardless of the method used. The pipe will have no weld or seam, making it ideal for anodizing and other finishing procedures.
Manufacturing Process of Aluminum Seamless Pipe
The seamless aluminum pipe is produced using two methods. First, Pushing a hollow aluminum billet through a die and mandrel press with tremendous force at high temperatures. And the other, Using a solid billet through a piercer press and then a mandrel pierces and extrudes the billet in a second forward stroke. Regardless of the method used. The pipe will have no weld or seam, making it ideal for anodizing and other finishing procedures.
Standard of Aluminum Seamless Pipe
ASTM B210, ASTM B210M, ASTM B234, ASTM B234M, UNSPSC 40182200,
Standard of Aluminum Seamless Pipe
ASTM B210, ASTM B210M, ASTM B234, ASTM B234M, UNSPSC 40182200,
Application of Aluminum Seamless Pipe
Lighting,solar reflector plate.
Architectural appearance, interior decoration
Elevator,nameplate, bags.
Automotive interior and exterior decoration.
Interior decoration: such as photo frame.
Household appliances, refrigerator, microwave oven,
Application of Aluminum Seamless Pipe
Lighting,solar reflector plate.
Architectural appearance, interior decoration
Elevator,nameplate, bags.
Automotive interior and exterior decoration.
Interior decoration: such as photo frame.
Household appliances, refrigerator, microwave oven,
